The Explorer Peak
Intelligent Power Management
Ride with precision using the latest Shimano drive units. The Explorer Peak offers custom motor tuning profiles, including "Soft Terrain Mode" and "Hard Terrain Mode," allowing you to fine-tune power output to match specific terrains and situations.
Innovative Battery Technology: Extended Range and Performance
Equipped with a 720Wh battery, the Explorer Peak ensures a large range and balanced ride. Using new battery cell technology, Explorer Peak batteries provide even greater energy density without increasing size.
Modern Luxuries for a Better Ride
Stay in control with the new integrated top tube display, providing essential information at a glance. The internal noise-canceling design prevents cable rattle, and integrated rubber chainstay protectors reduce chain slap noise, ensuring a smooth and quiet ride. UDH derailleur hanger makes for easy service and is compatible with Transmission drivetrains.
Don’t Stop Riding When the Season Changes
The Explorer Peak is not just a bike, it's an adventure machine for all seasons. Each build option comes equipped with the essentials including powerful 4-piston brakes, 1x drivetrains, and robust tubeless-ready wheels and tires.
Geometry
Units
| S | M | L | XL | |
|---|---|---|---|---|
| Top Tube | 590 | 614 | 637 | 660 |
| Seat Tube | 400 | 440 | 460 | 480 |
| Chainstay | 450 | 450 | 450 | 450 |
| Head Angle | 67° | 67° | 67° | 67° |
| Seat Angle | 75° | 75° | 75° | 75° |
| Head Tube | 90 | 100 | 120 | 130 |
| Bottom Bracket Height | 325 | 325 | 325 | 325 |
| Bottom Bracket Drop | 65 | 65 | 65 | 65 |
| Wheelbase | 1156.9 | 1184.1 | 1208.3 | 1232.6 |
| Fork Offset | 51 | 51 | 51 | 51 |
| Standover Height | 700 | 750 | 770 | 780 |
| Stack | 598 | 615 | 625 | 635 |
| Reach | 430 | 450 | 470 | 490 |
What’s my frame size?
Your height will determine a general recommended frame size. Occasionally, based on other body measurements, you may feel more comfortable on a different size. We recommend completing the 23-Point Custom Setup when completing your order.
Build Specs
Each Ari bike is built with the best components in a given category so you get the most bang for the buck. Each model has different build specs to choose from usually ranging in good, better, best order.
Specifications
| Explorer Peak Comp | Explorer Peak Elite |
|---|---|
|
Frame Ari Explorer Peak Carbon. UDH derailleur hanger. |
Frame Ari Explorer Peak Carbon. Fullmount/UDH interface. |
|
Fork Ari Racing Design Explorer Peak Carbon, tapered, 150x15mm thru axle, 180mm post mount |
Fork Ari Racing Design Explorer Peak Carbon, tapered, 150x15mm thru axle, 180mm post mount |
|
Rear Shock N/A |
Rear Shock N/A |
|
Drivetrain Shimano CUES U6000 11-Speed |
Drivetrain SRAM GX Eagle Transmission, 12-Speed |
|
Wheels Sun Ringle Mulefut SL 80mm, 32 hole, 27.5 |
Wheels Sun Ringle Mulefut SL 80mm, 32 hole, 27.5 |
|
Brakes TRP Slate EVO, 180/180mm rotors |
Brakes TRP Trail EVO, 180/180mm rotors |
|
Sizes S,M,L,XL |
Sizes S,M,L,XL |
|
Headset Cane Creek 40 ZS56/ZS56 sealed cartridge bearing |
Headset Cane Creek 40 ZS56/ZS56 sealed cartridge bearing |
|
Shifters Shimano CUES SL-U6000-11R |
Shifters SRAM AXS Pod |
|
Front Derailleur N/A |
Front Derailleur N/A |
|
Rear Derailleur Shimano CUES RD-U6000 |
Rear Derailleur SRAM GX Eagle Transmission, 12-Speed |
|
Cassette Shimano CS-LG400-11, 11-50t, 11-Speed |
Cassette SRAM XS-1275 GX Eagle, 10-52t, 12-speed |
|
Crank SAMOX E-Fat Bike Shimano Interface |
Crank SAMOX E-Fat Bike Shimano Interface |
|
Chainrings SAMOX E-Fat Bike 32t narrow wide, steel |
Chainrings SRAM T-Type 32t |
|
Drive Unit Shimano EP6 motor system |
Drive Unit Shimano EP801 motor system |
|
Battery Darfon 720w integrated battery |
Battery Darfon 720w integrated battery |
|
Chain Shimano CN-LG500 |
Chain SRAM GX Eagle Transmission Flat-Top, 12-Speed |
|
Handlebars Ari Team 31.8, width 780/800mm, 25mm rise, 9° back sweep, 5° Up sweep, bar-customized sizing through Ari Custom Setup |
Handlebars Ari Team 31.8, width 780/800mm, 25mm rise, 9° back sweep, 5° Up sweep, bar-customized sizing through Ari Custom Setup |
|
Stem Ari Alloy, 31.8mm |
Stem Ari Alloy, 31.8mm |
|
Tape/Grips Ergon GA20, black |
Tape/Grips Ergon GA20, black |
|
Saddle WTB Volt |
Saddle WTB Volt |
|
Seatpost TranzX JD-YS105J, travel adjust 30mm- customized sizing through Ari Custom Setup |
Seatpost TranzX JD-YS105J, travel adjust 30mm- customized sizing through Ari Custom Setup |
|
Pedals Available Separately |
Pedals Available Separately |
|
Rims Sun Ringle Mulefut SL 80mm, 32 hole, 27.5, Disc, Tubeless Ready |
Rims Sun Ringle Mulefut SL 80mm, 32 hole, 27.5, Disc, Tubeless Ready |
|
Hubs Sun Ringlé SRC 197x12, 150x15, HG, E-Bike specific (steel axel and freehub) |
Hubs Sun Ringlé SRC 197x12, 150x15, XD, E-Bike specific (steel axel and freehub) |
|
Spokes Wheelsmith DB14 |
Spokes Wheelsmith DB14 |
|
Tires Maxxis Colossus 27.5x4.5, EXO, tubeless ready |
Tires Maxxis Colossus 27.5x4.5, EXO, tubeless ready |
|
Tubes 27.5x4.5 Presta Valve for Fat Bike |
Tubes 27.5x4.5 Presta Valve for Fat Bike |
