Salsa Heyday! Cues

Overview

The frame utilizes 197 mm rear spacing to accommodate up to 5″ tires, and the 100 mm threaded bottom bracket allows a wide range of crank (Q-factor) choices. Alternator 1.0 dropouts allow for short chainstays and easily support single speed or geared drivetrain options. The Heyday! can do it all.

Features

Designed with a low and rearward center of gravity for increased stability when navigating challenging terrain

Bearpaw Aluminum fork with two sets of Three-Pack mounts

Aluminum frame includes two bottle mounts inside frame triangle and down tube mounts for a bottle, pump, repair kit, or other accessory

Alternator 1.0 dropouts

Full-length internal cable housing routing, internal dropper post routing, and 1x or 2x drivetrain compatible

Compatible with Salsa Alternator 190 Rear Rack using Salsa Rack-Lock or Post-Lock

Specs

Frameset

Frame: Salsa Heyday! AL
Fork: Salsa Bearpaw Aluminum

Drivetrain

Front Derailleur: N/A
Rear Derailleur: Shimano CUES U6000
Cassette: Shimano CUES LG400-10, 11–48t, 10-speed
Chain: Shimano CUES LG500
Crankset: Samox TAM37 Alloy, direct-mount chainring, 30t
Shifter: Shimano CUES U6000-10R

Brakes and Rotors

Brake Levers: Tektro HDM275
Brake Calipers: Tektro HDM275
Rotors: Tektro TR160 (6-bolt, 160mm front and rear)
Bottom Bracket: Samox, BSA, 24mm spindle, 100mm

Components

Headset: FSA Orbit 1.5B ZS NO.57B
Stem: Salsa Guide Trail 31.8
Handlebar: Kalloy 31.8 mm
- XS–SM: 740mm, 0mm rise
- MD–XL: 780mm, 15mm rise
Grips / Bar Tape: Salsa File Tread
Seatpost: Kalloy
- XS–SM: 350mm
- MD–XL: 400 mm
Saddle: WTB Volt Medium

Wheels

Front Hub: SUNRingle SRC 15 x 150mm
Rear Hub: SUNRingle SRC 12 x 197mm
Spokes: Butted stainless, black
Rims: SUNRingle Mulefüt SL 80mm
Front Tire: 45NRTH Dillinger 5, 26 x 4.6″, 60TPI, studdable, tubeless-ready
Rear Tire: 45NRTH Dillinger 5, 26 x 4.6″, 60TPI, studdable, tubeless-ready

Frame measurements (mm)	XS	SM	MD	LG	XL
A. Effective Top Tube	573	594	615	636	657
B. Stand Over	678	685	720	758	774
C. Reach	392	410	428	446	464
D. Stack	593	602	611	621	630
E. Total Seat Tube Length	406	406	457	508	558
F. Headtube Length	100	110	120	130	140
G. Headtube Angle	69	69	69	69	69
H. Seat Tube Angle	73	73	73	73	73
I. BB Drop	63	63	63	63	63
J. BB Height	–	–	–	–	–
K. Chainstay Length	440–457	440–457	440–457	440–457	440–457
L. Fork Length Axle to Crown	483	483	483	483	483
M. Fork Offset	51	51	51	51	51
N. Wheelbase	1085	1107	1129	1150	1172

Component measurements (mm)
Crank Arm Length	165	165	165	170	170
Handlebar Width	740	740	780	780	780
Stem Length	60	60	70	70	70
