Sizing to be used as a reference only. Please check with a local authorized Liv or Giant dealer to determine the correct size.
Available sizes may vary from country to country.
|
ONE SIZE |
| A SEAT TUBE LENGTH (inch) |
10.6 |
| B SEAT TUBE ANGLE |
72.0° |
| C TOP TUBE LENGTH (inch) |
20.5 |
| D HEAD TUBE LENGTH (inch) |
4.7 |
| E HEAD TUBE ANGLE |
70.0° |
| F FORK RAKE (inch) |
1.6 |
| G TRAIL (inch) |
2.7 |
| H WHEELBASE (inch) |
38.4 |
| I CHAIN STAY LENGTH (inch) |
16.1 |
| J BOTTOM BRACKET DROP (inch) |
1.6 |
| K STACK (inch) |
21 |
| L REACH (inch) |
13.6 |
| M STAND OVER HEIGHT (inch) |
21.5 |
| N HANDLEBAR WIDTH (inch) |
22 |
| O STEM LENGTH (inch) |
2.4 |
| P CRANK LENGTH (inch) |
5.5 |
| Q WHEEL SIZE |
24 |
SPECS
-
Sizes
one size
-
Colors
Trekking Green
-
Frame
ALUXX-grade aluminum
-
Fork
Giant Custom, 50mm
-
Shock
N/A
-
Handlebar
Giant Kids, alloy, 31.8mm, 10-degree rise, 60mm, custom taper design
-
Grips
Giant Junior, custom taper design
-
Stem
forged alloy Ahead, 10-degree
-
Seatpost
alloy, single-bolt, 27.2x250mm
-
Saddle
Explora Jr.
-
Pedals
platform
-
Shifters
Shimano REVOSHIFT, 1x7
-
Front Derailleur
N/A
-
Rear Derailleur
Shimano Tourney
-
Brakes
mechanical disc [F]160mm, [R]140mm rotors
-
Brake Levers
alloy, junior MTB
-
Cassette
14x34
-
Chain
KMC HV500
-
Crankset
alloy, 32t, 140mm
-
Bottom Bracket
semi-cartridge
-
Rims
Giant Kids 24", alloy
-
Hubs
disc brake, 28h
-
Spokes
stainless, 14g
-
Tires
Giant Junior Sport, 24x1.95", 22 tpi
-
Extras
bell, kickstand, fender, rear derailleur protector
-
Weight
10 kg (22 lbs 22 oz) - Size (24) w/o pedals
